| 产品尺寸 | 分辨率 | 显示 | 比例 | 尺寸（ W*H*T ) | 通信接口 | PIN | 参考型号 |
| 1.77 | 128*160 | TN | 竖屏 | 32.5*42*2.45mm | SPI | 14Pin | WK17757 |
| 1.9 | 170*320 | IPS | 长条屏 | 25.8*49.72*1.5mm | SPI | 16Pin | T19P00 |
| 2 | 220*176 | TN | 横屏 | 46.1*40.96*2.53mm | RGB | 40Pin | T20P96 |
| 3.95 | 480*480 | IPS | 方屏 | 74.83*78.98*2.0mm | MIPI | 24Pin | T395P00 |
| 3.95 | 720*720 | IPS | 方屏 | 74.83*78.98*2.0mm | MIPI | 24Pin | New |
| 6.95 | 600*1024 | IPS | 竖屏 | 95*136.1*2.6mm | MIPI | 40Pin | T70P170 |
| 11.6 | 1920*1080 | IPS | 横屏 | 268*157.97*2.75mm | EDP | 30Pin | T116P02 |
| 1.45 | 360(RGB)*360 | 全视角65度 | 圆屏 | 39.56*41.82*1.57 | MIPI | 14Pin | T145P00 |
| 1.72 | 300(RGB)*344 | 全视角65度 | 竖屏 | 32.70*38.57*1.75 | MIPI | 14Pin | T172P00 |
| 2 | 400(RGB)*454 | IPS | 竖屏 | 36.02*43.23*1.59 | MIPI | 24Pin | T20P315 |
| 2.13 | 122*250 | 全视角65度 | 竖屏 | 27.07*56.20*1.28 | SPI | 24Pin | T213P01 |
| 5 | 800(RGB)*480 | 全视角65度 | 横屏 | 75.36*120.26*2.73 | 24bit RGB | 40Pin | T50P168 |
| 10.1 | 1200(RGB)*1600 | 全视角65度 | 竖屏 | 157.86*211.88*1.05 | MIPI | 30Pin | FOG-T101P88 |
