| 产品尺寸 | 分辨率 | 显示 | 比例 | 尺寸（ W*H*T ) | 通信接口 | PIN | 参考型号 |
| 0.96 | 80*160 | IPS | 竖屏 | 13.5*27.95*1.5mm | MCU/SPI | 8Pin | T096P07-01 |
| 1.14 | 135*240 | IPS | 竖屏 | 17.6*31*1.45mm | SPI | 13Pin | T114P00 |
| 1.22 | 240*240 | IPS | 横屏 | 25.76*28.16*1.84mm | RGB | 24Pin | T122P03CQ |
| 1.3 | 240*240 | IPS | 横屏 | 26.2*29.22*1.5mm | SPI | 16Pin | T13P06 |
| 1.4 | 240*240 | IPS | 横屏 | 29.1*30.85*1.35mm | SPI | 13Pin | T14P07/09 |
| 1.4 | 320*320 | IPS | 横屏 | 28.64*30.83*1.36mm | SPI/MIPI | 13Pin | T14P08 |
| 1.44 | 128*128 | TN | 横屏 | 28.2*32.74*2.1mm | SPI | 24Pin | T144P21 |
| 1.54 | 240*240 | IPS | 横屏 | 31.52*33.72*1.73mm | SPI | 10Pin | T154P05 |
| 1.78 | 320*385 | IPS | 竖屏 | 31.05*40.35*1.65mm | SPI/MIPI | New | |
| 2.4 | 240*320 | TN | 竖屏 | 42.7*60.2*2.4mm | MCU/SPI | 40Pin | WK24196 |
| 2.4 | 240*320 | IPS | 竖屏 | 42.72*60.26*2.15mm | RGB/SPI | 40Pin | T24P170CK |
| 2.47 | 480*480 | IPS | 圆屏 | 69.19*71.74*2.47mm | RGB/MIPI | 40Pin | T247P00 |
| 2.8 | 240*320 | TN | 竖屏 | 50*69.2*2.45mm | MCU | 27Pin | T28P63 |
| 2.8 | 240*320 | IPS | 竖屏 | 50*69.2*2.45mm | MCU | 27Pin | WK28169 |
| 2.99 | 268*800 | IPS | 长条屏 | 26.96*80.08*1.68mm | MIPI | 25Pin | T30P195 |
| 3.5 | 320*480 | TN | 竖屏 | 52.96*81.34*2.28mm | RGB/MIPI | 24Pin | T35P67 |
| 3.5 | 320*240 | TN | 横屏 | 76.9*63.9*3.1mm | RGB | 54Pin | BL35023 |
| 3.5 | 320*240 | IPS | 横屏 | 76.95*63.95*3.2mm | RGB | 54Pin | WK35063 |
| 3.5 | 480*800 | IPS | 竖屏 | 51.32*86.61*2.15mm | RGB | 45Pin | T35P70 |
| 4.3 | 480*272 | TN | 横屏 | 105.5*67.2*2.9mm | RGB | 40Pin | T43P65-01 |
| 4.3 | 480*272 | IPS | 横屏 | 105.5*67.2*2.9mm | RGB | 40Pin | T43P82 |
| 4.3 | 800*480 | IPS | 横屏 | 105.5*67.2*2.9mm | RGB | 40Pin | WK43188 |
| 5 | 480*854 | IPS | 竖屏 | 66.4*120*2.35mm | RGB | 40Pin | T50P37 |
| 5 | 800*480 | IPS | 横屏 | 120.80*75.8*2.85mm | RGB | 40Pin | T50P53 |
| 5 | 720*1280 | IPS | 竖屏 | 65.3*119.3*1.73mm | MIPI | 40Pin | WK50087 |
| 5.5 | 720*1280 | IPS | 竖屏 | 72.24*131.61*1.8mm | MIPI | 30Pin | T55P01CK |
| 7 | 800*480 | IPS | 横屏 | 165.86*105.06*7.2mm | RGB | T70P155 | |
| 7 | 1024*600 | IPS | 横屏 | 163.8*97*2.6mm | LVDS/MIPI | 40Pin | WK70269 |
| 7 | 1024*600 | IPS | 横屏 | 164.65*99.7*2.87mm | 40Pin | T70P223CQ | |
| 7 | 800*1280 | IPS | 竖屏 | 99.85*161.7*2.6mm | MIPI | 24Pin | T70P199 |
| 8 | 800*1280 | IPS | 竖屏 | 114.7*184.2*2.7mm | MIPI | 30Pin | T80P102 |
| 9 | 1024*600 | IPS | 横屏 | 210.7*126.5*5.2mm | LVDS | 40Pin | T90P08 |
| 10.1 | 1024*600 | TN | 横屏 | 235*143*5.1mm | RGB | 50Pin | T101P43 |
| 10.1 | 1024*600 | IPS | 横屏 | 235*143*4.55mm | LVDS/MIPI | 40Pin | T101P11-01 |
| 10.1 | 800*1280 | IPS | 竖屏 | 143*228.6*2.6mm | LVDS/MIPI | 40Pin | WK10146 |
| 10.1 | 800*1280 | IPS | 竖屏 | 142.64*228.55*4.5mm | MIPI | 40Pin | T101P39 |
| 2.13 | 122*250 | Mono | 横屏 | 27.07*56.20*0.95 | SPI | 24Pin | T213P00 |
