| 产品尺寸 | 分辨率 | 显示 | 比例 | 尺寸（ W*H*T ) | 通信接口 | PIN | 参考型号 |
| 1.5 | 160*240 | TN | 横屏 | 37.1*32.7*2.5mm | 40Pin | T15P11-19 | |
| 2 | 480*360 | IPS | 横屏 | 46.1*40.96*2.54mm | RGB/MIPI | 40Pin | T20P162-01 |
| 2 | 240*320 | IPS | 竖屏 | 35.72*51.29*1.61mm | RGB | 40Pin | T20P217-01 |
| 2 | 320*240 | IPS | 横屏 | 45*39*2.58mm | SPI | 14Pin | T20P215 |
| 2 | 320*240 | TN | 横屏 | 46*40.9*2.53mm | RGB | 40Pin | T20P189-02 |
| 2.31 | 320*240 | TN | 横屏 | 55.9*48*3.1mm | RGB | 40Pin | T23P13-02 |
| 2.31 | 480*360 | IPS | 横屏 | 55.2*47.55*2.8mm | RGB | 16Pin | T23P32 |
| 2.36 | 160*234 | TN | 横屏 | 55.2*47.55*2.8mm | RGB | 40Pin | T24P167 |
| 2.45 | 272*480 | IPS | 竖屏 | 34.28*60.46*2.11mm | RGB/MIPI | 12Pin | T245P01 |
| 2.7 | 320*240 | TN | 竖屏 | 39.85*68.25*2.8mm | RGB | 40Pin | T27P58 |
| 3 | 320*240 | TN | 竖屏 | 43.44*75.31*2.58mm | RGB | 40Pin | T30P176 |
| 3 | 360*640 | IPS | 竖屏 | 43.33*75.31*2.6mm | MIPI/RGB | 40Pin | T30P131 |
| 3 | 480*854 | IPS | 竖屏 | 42.64*74.51*2.0mm | MIPI/RGB | 40Pin | T30P147-02 |
| 3.2 | 240*320 | TN | 竖屏 | 55.04*77.7*2.5mm | SPI/MCU | 10Pin | WK32066 |
| 3.2 | 376*960 | IPS | 竖屏 | 31.2*76.6*2.4mm | MIPI/RGB | 12Pin | T32P09/11 |
| 3.97 | 480*800 | TN | 竖屏 | 57.14*96.85*2.2mm | MIPI | 31Pin | T397P04 |
| 3.97 | 480*800 | IPS | 竖屏 | 57.14*96.85*2.15mm | MIPI | 25Pin | T397P08 |
| 6.2 | 800*480 | TN | 横屏 | 155.2*88.2*5.0mm | RGB/LVDS | 60Pin | T62P00 |
| 6.86 | 480*1280 | IPS | 横屏 | 180.6*66.35*4.64mm | MIPI | 40Pin | T68P01 |
| 9.2 | 1920*384 | IPS | 横屏 | 238.58*58.65*7.0mm | LVDS/RGB | 30pin | T92P01 |
| 9.35 | 320*1280 | IPS | 横屏 | 261.42*70.89*6.61mm | MIPI | 40Pin | T935P08-01 |
| 9.35 | 480*1920 | IPS | 横屏 | 261.42*70.89*6.61mm | MIPI | 40Pin | T935P07-01 |
| 10.25 | 1280*480 | IPS | 横屏 | 258.60*107.00*6.31mm | LVDS/RGB | 60Pin | T1025P00 |
| 10.25 | 1920*720 | IPS | 横屏 | 258.60*107.00*6.31mm | 50Pin | HSD103JPW2-F10-HY | |
| 11.88 | 440*1920 | IPS | 竖屏 | 292.58*71.30*4.65mm | MIPI | 40Pin | T1188P00 |
